Round Baler for Grass

WDB800 round type hay baler adopts eccentric pickup and utilizes hydraulic control to make pickup work up and down. The pickup has 4 rows of 64 tines with high efficiency. The large chamber capacity is equipped with 16 strong rollers for making bale more solid. 2100mm pickup width, 1200mm feeding width, roller speed 124rpm, bale weight 300-400kg, baling chamber diameter 1300mm and length 1200mm. This baler can match with tractor 100-200hp. Smaller size round baler is also available.

Quantity:
  • WDB800
  • WORLD
  • WDB800

ITEM

UNIT

DATA

Model

/

WDB800

Picking   up width

mm

2100

Feeding   width

mm

1200

Roller   speed

r/min

124

Rollers   number

pcs

16

Bale   size

/

Ф1300×1200

Control   system

/

12V/DH35-4K

Bale   weight

kg

300~400

Size   of baler house

mm

ф1300×1200

Working   dimensions

mm

4290×2830×2400

Travelling   mode

/

With   tractor

Match   tractor power

hp

100~12073.5-88.8Kw

PTO

r/min

540

Machine   weight

kg

3020

Max.   tracking weight

kg

600

Efficiency

Kg/h

≥9000
