WJC
WORLD
WJC
| Model | WJC35 | WJC45 | WJC60 | WJC70 | WJC75 |
| Rated Operating Capacity(kg) | 500 | 700 | 850 | 1000 | 1050 |
| Tipping load(kg) | 1000 | 1400 | 1700 | 2000 | 2100 |
| Bucket Capacity(m3) | 0.25 | 0.36-0.45 | 0.4-0.5 | 0.5 | 0.55 |
| Work weight(kg) | 2200 | 2705 | 3150 | 3400 | 3500 |
| Travel speed(km/h) | 12 | 12 | 12 | 16 | 18 |
| Work flow(L/min) | 50L | 62.5 | 62.5 | 75 | 75/125 |
| Fuel tank volume(L) | 50L | 50 | 60 | 70 | 90 |
| Tyre model | 10.0/75-15.3 | 10-16.5 | 12-16.5 | 12-16.5 | 12-16.5 |
| Overall dimension(LxWxH) (mm) | 2900×1300×2000 | 3200×1830×2030 | 3840×1820×2080 | 3345×1850×2040 | 3560×1900×2050 |
| Height at Maximum Extension(mm) | 3300 | 3670 | 3690 | 3780 | 4070 |
| Hinge Pin Height(mm) | 2725 | 2900 | 2920 | 3150 | 3150 |
| Width with Bucket(mm) | 1300 | 1740 | 1820 | 1900 | 1900 |
| Track Width(mm) | 1080 | 1450 | 1500 | 1500 | 1500 |
| Wheelbase(mm) | 891 | 991 | 991 | 1020 | 1185 |
| Ground Clearance(mm) | 150 | 185 | 205 | 260 | 200 |
| Dumping Angle(°) | 40 | 40 | 40 | 40 | 40 |
| Dumping Height(mm) | 2050mm | 2310 | 2330 | 2300 | 2450 |
| Maximum Reach(mm) | 790mm | 710 | 710 | 710 | 710 |
| Engine model | Changchai 385 | Xinchai 490BPG | Xinchai 498BPG | Deutz D226B-4 | Deutz D226B-4 |
| Engine power(HP/rpm) | 35/2500 | 50/2650 | 60/2650 | 80/2500 | 75/2500 |
| Type | Direct injection, in-line, water cooling, 4 stroke diesel engine | ||||
| Displacement(L) | 2.54 | 2.54 | 2.54 | 4.2 | 3.9 |
| Model | WJC35 | WJC45 | WJC60 | WJC70 | WJC75 |
| Rated Operating Capacity(kg) | 500 | 700 | 850 | 1000 | 1050 |
| Tipping load(kg) | 1000 | 1400 | 1700 | 2000 | 2100 |
| Bucket Capacity(m3) | 0.25 | 0.36-0.45 | 0.4-0.5 | 0.5 | 0.55 |
| Work weight(kg) | 2200 | 2705 | 3150 | 3400 | 3500 |
| Travel speed(km/h) | 12 | 12 | 12 | 16 | 18 |
| Work flow(L/min) | 50L | 62.5 | 62.5 | 75 | 75/125 |
| Fuel tank volume(L) | 50L | 50 | 60 | 70 | 90 |
| Tyre model | 10.0/75-15.3 | 10-16.5 | 12-16.5 | 12-16.5 | 12-16.5 |
| Overall dimension(LxWxH) (mm) | 2900×1300×2000 | 3200×1830×2030 | 3840×1820×2080 | 3345×1850×2040 | 3560×1900×2050 |
| Height at Maximum Extension(mm) | 3300 | 3670 | 3690 | 3780 | 4070 |
| Hinge Pin Height(mm) | 2725 | 2900 | 2920 | 3150 | 3150 |
| Width with Bucket(mm) | 1300 | 1740 | 1820 | 1900 | 1900 |
| Track Width(mm) | 1080 | 1450 | 1500 | 1500 | 1500 |
| Wheelbase(mm) | 891 | 991 | 991 | 1020 | 1185 |
| Ground Clearance(mm) | 150 | 185 | 205 | 260 | 200 |
| Dumping Angle(°) | 40 | 40 | 40 | 40 | 40 |
| Dumping Height(mm) | 2050mm | 2310 | 2330 | 2300 | 2450 |
| Maximum Reach(mm) | 790mm | 710 | 710 | 710 | 710 |
| Engine model | Changchai 385 | Xinchai 490BPG | Xinchai 498BPG | Deutz D226B-4 | Deutz D226B-4 |
| Engine power(HP/rpm) | 35/2500 | 50/2650 | 60/2650 | 80/2500 | 75/2500 |
| Type | Direct injection, in-line, water cooling, 4 stroke diesel engine | ||||
| Displacement(L) | 2.54 | 2.54 | 2.54 | 4.2 | 3.9 |
