Road Construction Motor Grader

The self-propelled articulated motor grader is suitable for large-scale land leveling in foundation constructions. It can be used for ditching, grading, slope scraping-bulldozing, ripping, virgin land scarifying and snow-removing etc., which is modernized construction equipment of multi-functions and high-efficiency for high-class highway, railway, airport, harbors, dams, industrial ground and farmland. Whole engine hood and spacious operators cab for good visibility within 1mX1m distance, ease to maintain and operate. Torque converter and power-shift gearbox is operated electro-hydraulically; all the instruments and warning lights are indicated.

Quantity:
  • PY
  • WORLD
  • PY
MODEL
PY220C-2     PY180C-2 PY165C-2
Operating massKg169001600015000
Front axle loadKg582051504150
Rear axle loadKg110801085010850
Max forward speedKm/h36.838.240.4
Max backward speedKm/h24.824.525.7
Speed gear number
F6/R3F6/R3F6/R3
Turning radiusmm780078007500
Hydraulic system pressureMpa181818
Blade length×heightmm3965×6103965×6103660×610
Front wheeltrackmm 215021502150
Rear wheeltrackmm 234023402340
wheelbasemm 636263626062
Engine modle
6CTA8.36BTA5.96BTA5.9
Engine powerKW158132125
Overall dimensionsmm 8585×2790×33408585×2790×33408585×2790×3340
